規(guī)格說明
Contact Rating: 500 mA @ 120 V AC or 28 V DC; 250 mA @ 250 V AC;
Mechanical Life:100,000 actuations at full load.
Electrical Life: 50,000 make-and-break cycles at full load
Contact Resistance:Below 30 milliohms typ. initial @ 2-4 V DC, 100 mA, for both silver and gold plated contacts
Dielectric Strength:500 Vrms min. @ sea level
Insulation Resistance:10? ohms min.
Operating Temperature:–30oC to 65oC
Certifications:ROHS
